UAV forced displacement equipment gun type electromagnetic interference instrument 1500m automatic driving

Thank you for using this anti gun of Bochuangspacetime brand UAV.
In order that you can operate the equipment skillfully as soon as possible, we are equipped with a detailed user manual, from which you can obtain knowledge about product introduction, use method, system setting, safety precautions and so on.
The anti gun of this Bochuang spacetime brandUAVhas passed the strict certification of the safety and police electronic equipment quality testing center, electronic product quality testing center and electromagnetic leakage emission protection product testing center of the Ministry of public security.
We are very careful and rigorous in compiling this manual and believe that the information provided in the manual is correct and reliable. However, there will inevitably be errors and omissions. Please forgive me and warmly welcome your correction. Bochuang spacetime brand has focused on radio wave jammers for more than 20 years and can customize and combine interference frequencies according to customer needs.

Product features;
◎ Bochuang spacetime brand UAV jammer adopts UHF broadband seamlessjammingtechnology
◎ single channel switching technology controls power output.
◎ the effective power (channel power) is high, and a single channel of 20 watts can interfere at a distance of 1500 meters.
◎ effective segmentation only interferes with UAV control and video transmission frequency, and will not interfere with other frequencies.
◎ imported devices. The slow start circuit design can avoid the ignition phenomenon caused by mechanical switch, with high integration and stable operation.
◎ it adopts built-in battery and plug-in battery, which can be replaced at any time. It can last about 1 hour and charge for 4 hours.
◎ four SMA / n-type interfaces for connecting directional antenna (900m / 2.4G / 1.5g / 5.8G)
◎ one power charging interface (DC24V in)

Operation process;
When all switches of Bochuang space-time UAV jammer are turned on, the UAV will be forced to land. When GPS is turned off and 2.4g/5.8g/900m is turned on, the UAV will lose control. At this time, the UAV will return. When the 2.4g/5.8g/900m is turned off and the GPS is turned on, the positioning of the UAV is lost. At this time, the UAV remote control can be controlled.
This model is a space-time brand of Bochuang, which is specifically aimed at visual UAV interference. The effective distance is that the flying hand is about 100 meters away from the UAV, and the interference is more than 1500 meters.
Wireless communication must ensure sufficient carrier interference ratio (signal-to-noise ratio) in order to receive effectively and complete communication. The Communication Signal Jammer destroys the reception conditions of UAV and cuts off the communication connection between UAV and remote control transmission by generating interference signals with the same frequency as UAV. Achieve the effect of interfering with communication.
The interference power is certain, and the shielding radius of unobstructed space is controlled by path attenuation and remote control transmission
The signal level is determined jointly. The following table shows the comparison table of distance and path attenuation. Then the coverage radius can be determined by the jammer's output channel power, remote control signal level and coverage line gain. The following formula:
Pch+Gat-L-FAF≥Prx
Where:
Pch : Minimum channel power output by jammer
Gat : Antenna gain
L : Path attenuation
FAF : Added value of path loss, 6-8db
Prx : Received signal strength
Distance and attenuation comparison table
L = 32 + 20logd + 20logf + FAF f f distance in megahertz D distance in kilometers

◎ will Bochuang spacetime brand UAV jammer interfere with the normal operation of other electronic equipment?
unable. This is because the electromagnetic signal sent by the UAV jammer completely falls within the working frequency band specified by the state, which will only shield the communication.
◎ is Bochuang brand jammer harmful to human body and mobile phone?
Please rest assured that the intensity of the transmitted electromagnetic signal is very weak, and the test data show that this signal intensity is far from enough
No harm to human body. At the same time, it only interferes with the forward signal, so that the UAV cannot establish contact with the operation remote control. Therefore, it will not cause any damage to the UAV itself.
◎ is there any difference in the distance between indoor and outdoor use of Bochuang spacetime brand UAV jammer?
yes. Generally speaking, the outdoor signal is used outdoors, so the indoor interference effect is poor. Strictly speaking: whether used indoors or outdoors,; The effective operating distance of UAV jammer is related to the electromagnetic environment and surrounding environment at that time. Such as distance from the, location, etc.
◎ after the UAV jammer of Bochuang spacetime brand works for a period of time, the casing heats up. Will it damage the machine if it works for a long time?
Thank you for your care. This is a normal phenomenon. In terms of design, we use the thermal conductivity of all aluminum casing to assist heat dissipation. Thus, the machine can work stably for a long time. Therefore, the heating of the casing will not damage the machine.
Endless Service
This manual collects various types of UAV jammers from Shenzhen Bochuang spatiotemporal Communication Technology Co., Ltd,
Due to the lack of time, there are inevitable omissions. In case of any unknown
Please forgive me and correct me. At the same time, we will help you at any time
Answer and serve you wholeheartedly.
We sincerely hope that this manual will bring you convenience,
In view of the standards, technical requirements and products involved in this manual
Various specifications of the products may change with the progress of technology and the passage of time. Therefore, we reserve the right to modify them without notice.

In the past twenty years, Shenzhen Bochuang space-time Communication Technology Co., Ltd. has always focused on the field of electronic information confrontation, and has made a small effort to promote the communication digital information security.
The company takes root in Shenzhen, the southernmost end of the motherland. With the help of the unique electronic components supply chain and scientific research advantage, we seize the historical opportunity brought by the high-speed development of China's information and wireless communication industry, insist on customer centered, based on the striving, and continue to innovate on the basis of customer demand, and win the respect and trust of the customers. From a small start-up company with only a few people, it has grown steadily to be the industry leader with a monthly turnover exceeding 6000 units. Today, our wireless signal shielding devices and solutions have been exported to more than 170 countries and regions around the world.
The company has a group of research and development teams from top domestic universities, professors, doctoral candidates and all kinds of professionals. BCSK-101 series products: conference information secret machine (mobile phone signal console), computer cipher secrecy cabinet, portable mobile lighting system, as the leading information shielding equipment and solution provider, we provide competitive wireless signal control shielding solutions and equipment for consumers in all walks of life. We insist Focusing on the basic communication network, the new generation of 4G and wireless LAN and other fields, the company is always in the forefront of the industry and leads the development of the industry.
We believe that the future will be a world of wireless communication and all corners of the world, information security and wireless communication signal control will be a blue sea "just need" field, aiming at the frontier of international secrecy science and technology, and service information security is the goal of the struggle of space and time communication of Bo Chuang.
