Bochuang spacetime high-power UAV driver 900MHz / 433MHz /
1.2g/2.4g/5.8/gps frequency output 500-2000m
UAV jammer
The application of Wireless Signal Jammer in many fields and
industries is very important and necessary. View the details of the
latest 800W high-power full frequency wireless signal jammer, as
shown below.This is a high-energy UAV jamming equipment, which can
be used to block unwanted signals in VIP escort, military
exercises, municipal halls, prisons, detention centers, police
checkpoints, prisons, bomb disposal and other occasions, as well as
vehicle mounted remote-controlled explosive devices.According to
the standard requirements, the interference range of high output
power interference can reach 500-2000m, and the frequency band is
433mhz-900mhz / 1.2g/2.4g/5.8g/gps. With well-designed cooling
system, the equipment can work continuously all day. It adopts
shockproof and portable solid shell, which is easy to use and has
better durability. Each module of the signal jammer is controlled
separately to improve the blocking efficiency in the case of
possible uncertain factors such as distance and obstacles. The
device is equipped with omni-directional antenna, which can block
360 degree wireless signals.If you are looking for professional VIP
team safety
signal jamming, this high-power wireless jammer will be an efficient and reliable
choice.
Product Features:
l Using UHF broadband interference technology.
l High effective power (channel power) and large interference
radius.
l Imported device, slow start circuit design can avoid the
mechanical switch fire phenomenon, high integration, stable work.
l Perfect self-protection function. When the device is warned of
overheating fault, the shielding device will automatically shut
down the failed module to avoid the damage of the shielding device.
Product Specification:
| brand | Bo Chuang space time | |
| model | BCSK-LG006 | |
| Channel | Working Frequency | Output Power(±3dBm) |
| CH1 | 900 MHz | 44.77dBm |
|
CH2 | 433MHz | 44.77dBm |
| CH3 | 1120-1280MHz | 47dBm |
| CH4 | 1560-1580MHz | 47dBm |
| CH5 | 2400-2500MHz | 48.75dBm |
| CH6 | 5750-5850 MHz | 48.75dBm |
| Power: AC 220V |
Power Consumption : 1000W Mainframe weight: 53.6Kg Size(L×W×H):800×500×310 mm |
| Humidity: 5%-95% Running Temperature: -35 to +80 ℃ |
Product Details:
1. System accessory table
| No | Name | Qty | Unit | Remark |
| 1 | Antenna | 8 | pcs | Omnidirectional |
| 2 | Wire controller | 1 | pcs | |
| 3 | Line controller control line | 1 | pcs | Standard |
| 4 | Spare Line controller control line | 1 | pcs | 20M |
| 5 | Power Line | 1 | pcs | Standard |
| 6 | Hand-pull Box | 1 | pcs | System Accessary |
2. Omnidirectional Antenna Parameter List
| Input impedence | 50Ω |
| standing wave | ≤1.8 |
| Gain | 3dBi |
| Power Capacity | 150W |
| Direction of Polarization | Vertical Polarization |
| Cross Modulation | <-107dBm |
| Interface Type | 7/16 or N-K |
| Lightning Protection | Direct Grounding |
| Wind Protectionnn | 60(m/s) |
| Pole Diameter | Φ25/40(mm) |
3. Product Application Place
Tag: High Power Signal Jammer for court using.
Product Applications:
- Prisons
- Recording Studios
- Banks
- Contract Tendering Rooms
- Churches
- Classrooms
- Testing Facilities
- Security Services
- Military Units
- Secret Services
- News Conference Rooms
- Libraries, Museums
- Courts
- Border Patrol and Drug Enforcement
- Customs
- Etc.
Product Usage:
Step 1 - Open the box
- Open the box. Keep unpacked boxes ready for future removal or
shipment.
- check that the open equipment and accessories are in good
condition. If any defects or damage are found, please contact your
supplier as soon as possible.
Step 2 - Connecting antenna
- Open the suitcase and take out the antenna. Note: do not activate
the shield until the antenna and shield are not well connected,
otherwise, the shield will be severely damaged. All costs and
consequences arising from this will be borne by the user himself.
- Each antenna is connected to the
RF output interface of the host computer one-to-one.
Step 3 - Start Jammer
- Connect the host AC~220V port with the power cord in the suitcase:
then dial the side red knob switch to the "1" file;
- The start and output power adjustment of the wire controller:
1) Connection wire controller
The 6pin wire control connection line is connected to the 6pin wire
control connection
port on the side of the chassis;
2) Control the output and output power of the power amplifier with
a wire controller.
[ALL Ch]: screen all 4Channel on / off buttons;
[ALL PA]: power output adjustment keys for all 4Channel of the
shield;
[CHX]: the output of Channel X is the Channel number of 1 ~ 8 when
the output of
Channel X is turned on / off alone;
[PAX]: regulating the power output of ChannelX alone X is the
Channel number of 1 / 8.
The output power regulation is divided into five sections: 20: 20
and 40.
Step 4 - Turn off the Jammer
- the power output switch of each channel is closed;
- Power off:
1) Dial the red knob switch on the side of the chassis to "0";
2) Unplug the power cord;
