5g mobile phone
signal jammer with built-in ten band frequency mobile phone interference shield
in
school conference roo Brand: Bochuang spacetime
Product model: bcsk-nz110-5g
Product introduction:
Effectively shield all 2G / 3G / 4G /
5G mobile phones jammer, 2.4G (WiFi / WLAN Bluetooth) and other communication signals. The
built-in omni-directional antenna is used to form an
electromagnetic protection field in the place where the use of
wireless communication equipment is prohibited by transmitting
specific electromagnetic signals, so that the wireless
communication equipment in the place can not identify and connect
with the external communication signals, so as to cut off the
contact between the wireless communication tools in the place and
the outside world and eliminate the hidden danger of information
security. It is applicable to information security and
confidentiality places such as examination room, conference room,
prison, detention center, court, interrogation room and
confidential room.
Product features:
1. Effectively
shield 2G / 3G / 4G / 5G mobile phones and 2.4G (WLAN / WiFi / Bluetooth)
and other communication
signals;
2. The equipment adopts high-density heat sink, three low-noise
fans and chassis to form an efficient cooling and heat dissipation
system with stable, safe and reliable performance;
3. The equipment can be equipped with built-in network control
board and data interface RJ45 according to the needs of users,
support TCP / IP protocol, have networking ability, manage and
switch each equipment on the terminal operation interface through
software and network, monitor the connection and working status of
each equipment, report faults in real time, and realize the
centralized network control and management function;
4. 11 built-in omni-directional antennas are adopted, which can
work directly after power on, and the installation, use and
management are simple;
5. Slow start circuit design to avoid mechanical switch ignition;
6. The electromagnetic radiation intensity of the equipment is far
lower than the industry standard and has no impact on human body;
7. The effective shielding range is 100 ~ 200m2 (field strength
RSSI ≤ - 75dbm, rsrp ≤ - 95dbm).
Technical parameters:
project parameter
Action type 2G, 3G, 4G, 5g, 2.4G (WLAN, WiFi, Bluetooth)
working frequency 2G:
Mobile: 930 ～ 960MHz / 1805 ～ 1825mhz
Telecom: 865 ~ 880mhz
Unicom: 1830 ~ 1850mhz
3G:
Mobile: 2010 ~ 2025mhz
Telecommunications: 2110 ~ 2125mhz
Unicom: 2130 ~ 2145mhz
4G:
Mobile: 1880 ～ 1920mhz / 2320 ～ 2370mhz / 2575 ～ 2635mhz
Telecommunication: 1860 ～ 1880MHz / 2370 ～ 2390mhz
Unicom: 2145 ~ 2170mhz / 2300 ~ 2320mhz
5G:
Mobile: 2515 ~ 2675mhz / 4800 ~ 4900mhz
Telecommunication: 3400 ~ 3500MHz
Unicom: 3500 ~ 3600MHz
Radio and television: 4900 ~ 4960mhz
WLAN / WiFi / Bluetooth: 2.4 ~ 2.4835ghz
Shielding range 100 ~ 200 ㎡ (field strength RSSI ≤ - 75dbm, rsrp ≤
- 95dbm)
weight About 3.5kg
working temperature - 30℃～+60℃
Product size 440mm (length) × 300mm (width) × 100mm thick
Transmit power About 50W
Power input AC160V～240V
Power output 12V 15A
Installation mode Upright, wall mounted
instructions:
1. Hang the equipment wall in the middle of any wall on the left
and right
sides of the place of use, or put it upright on the table. The ideal
installation height is 1.5 ~ 1.8m;
2. Connect the power adapter and power cord, insert the power cord
plug into the mains socket, turn on the power switch on the power
adapter, and the work indicator on the side of the equipment lights
up to start working;
3. The size of equipment shielding range depends on the
electromagnetic field strength of the place of use. The closer the
communication base station is to the place of use, the smaller the
equipment shielding range, and vice versa. When there is a
communication base station near the place of use or the area is
larger than the effective shielding range of the equipment, it is
recommended to use multiple equipment honeycomb installation to
ensure the shielding effect.
matters needing attention:
1. The equipment shall not be placed on the ground, and the
installation position shall be too low or too high, otherwise the
shielding effect will be reduced;
2. During installation and use, the power adapter shall be placed
under or under the equipment side to avoid interference with the
power adapter when the equipment is started and the equipment
cannot work stably;
3. The equipment reaches the normal working range, and the
electromagnetic field strength in the use place is ≤ - 75dbm,
otherwise the shielding range will be reduced or the shielding can
not be completely shielded;
4. When using, pay attention to correctly select the placement
position of the equipment to achieve the ideal shielding effect and
avoid shielding dead angle;
5. The equipment shall be placed in a well ventilated place as far
as possible, avoiding obstacles, strong heat source and strong
electric and magnetic source, so as to ensure the stability of
long-term working performance of the equipment.
Data Sheet:
| Product Name | 5g mobile
phone jammer | |
| brand | Bo Chuang space time | |
| model | BCSK-NZ110-5G | |
| Output port | Frequency | Output Power |
|
| CDMA800 | 851-894 MHz | 5W |
| LTE700 | 725-770 MHz | 5W |
| GSM900 | 925-960 MHz | 5W |
| LTE800 | 791-821 MHz | 5W |
| DCS1800 | 1805-1880 MHz | 5W |
| PCS1900 | 1920-1990 MHZ | 5W |
| 3G2100 | 2110-2170 MHz | 5W |
| GPSL1 | 1570-1580 MHz | 5W |
| WIFI2.4G | 2400-2500 MHZ | 5W |
| LTE2600 | 2620-2690MHZ | 5W |
| LTE2500(Option) | 2500-2700 MHZ | 5W |
| Power supply: AC adapter (AC220V) |
| The frequencies can be customized as the specific requirement |
| Semidiameter of interception:20-60m(depend on the
signal strength and environment condition) |
| RF output power :50 Watts Gross weight: 3.75KG |
| Size:390X300X120mm Working Hours:continuous |
| Humidity: 30%-95% Running Temperature: -20 to +55 Celsius Degree |
